Intellijel Designs Jellymix

Compact Stereo Performance Mixer

• Five stereo channels for synthesizers, drum computers, samplers, grooveboxes and other sources
• Hi-Z instrument input switchable for channel 1
• Muted channels are sent to the mute bus
• Adjustable stereo headphone output with level control and selectable source (Main / Muted)
• Main output with level control and LED level indicator
• Switchable stereo filters for main output with high-pass control
• Low-pass and resonance filter
• Five stereo inputs: 2x 6.3 mm jack, balanced
• Two stereo aux sends: 2x 6.3 mm jack, balanced
• Two external inputs: 2x 6.3 mm jack, balanced
• Stereo main output: 2x 6.3 mm jack, balanced
• Stereo headphone output: 6.3 mm jack
• Solid metal housing
• Dimensions (W x D x H): 277 x 122 x 66 mm
• Weight: 1.4 kg
• Includes external power supply (12 V DC, 2.5 A)

Controls and functions per channel:

• Level control
• LED indicators for signal level and overload
• Noise-free mute switch with LED
• Gain control: +26 dB
• Tilt EQ: ±10 dB, centre frequency 810 Hz
• Switchable high-pass filter: 150 Hz
• Routing switch: Main / Filter
• Two stereo aux: Off & Pre-/Post-fader switchable
