Blackmagic Design Videohub Mini 4x2 12G

Blackmagic Design

Blackmagic Design Videohub Mini 4x2 12G

Blackmagic Design Videohub Mini 4x2 12G

Mostrar tradução

Zero-Latency Router

For simultaneous routing of any combination of SD, HD and Ultra HD video signals
Features 4 12G-SDI inputs and 2 12G-SDI outputs
In addition, the crossbar has a 12G-SDI emergency connection for connecting external devices, as well as a USB-C webcam video output
In addition to SDI reclocking and external control via Ethernet, all SDI video standards up to 2160p/60 are supported
Power supply: 1 integrated AC power supply for 100–240 V, 50/60 Hz (IEC power cable not included)
Power consumption: Max. 17 watts
Dimensions: 140 x 46.3 x 173.3 mm
Weight: 0.92 kg

Connections:

SDI video inputs: 4
SDI video outputs: 2
SDI rates: 270 Mbit, 1.5 G, 3 G, 6 G, 12 G
All 4 video inputs with resync for clean switching
All SDI outputs with SDI resynchronisation
Webcam output: USB-C
Ethernet: supports 10/100/1000 Base-T
Computer interface: 1 USB-C 3.1 Gen 1 port for webcam output, software updates and connecting the Video Setup Utility
1 12 V DC input with reverse polarity protection
